435 Watt TopCon Monocrystalline Solar Panel (with Z-brackets)

Free Shipping
FEATURES YOU’LL LOVE

TopCon High Conversion Efficiency Mono-crystalline Silicon

Our household-sized panel. Warrantied for 30 years. Cable and MC4 connectors are included on the back of each panel. (4) Z-bracket mounting hardware included!

  • Zero LID
  • Module Efficiency up to 22.3%
  • SMBB + Half-cell tech, reduce internal current loss, improve module efficiency, minimize micro-crack, impacts, and improve module reliability
  • Non-destructive Slicing Tech, reduce micro-crack risk
  • Lower temperature coefficient (-0.29%/℃), lower operating temperature, increase the power generation
  • Excellent low irradiance performance, higher power output
  • Resistant to harsh environments
  • Anti PID
  • More energy yield, lower BOS and LCOE
  • Designed for Outdoor Use. IP68 junction box, high water proof level.
  • The panels are framed using heavy-duty anodized aluminum frames providing exceptional panel rigidity
specs

GENERAL SPECS

Maximum power (Pmax) 435W
Voltage at Pmax (Vmp) 32.13V
Current at Pmax (Imp) 13.54A
Open-circuit voltage (Voc) 38.75V
Short-circuit current (Isc) 14.27A
Temperature coefficient of Voc -0.29% / °C
Temperature coefficient of Isc +0.043%/ °C
Temperature coefficient of Pmax -0.330%/ °C
Maximum System Voltage 1500V DC
Number of Diodes 3
Junction box IP rating IP68
Maximum series fuse rating 25A
Operating temperature -40°C to 85°C
Power tolerance 0,+5W
Standard Test Condition Irradiance 1kW/sqm, Temperature 25°C, AM=1.5
Cell Type N type mono-crystalline TOP-CON
Number of cells 108 (6x18)
Cable lengh (includs connector) 1200mm
Cable size 12 AWG
Max test mechanical load 5400 Pa
Panel Dimension 67.8” x 44.6” x 1.2”
Shipping Weight 47.0 lbs (21.4 kg)
in the box
warranty & SHIPPING

$480 shipping charge for up to 31 panels



30-YEAR LINEAR POWER WARRANTY

10-YEAR PRODUCT WORKMANSHIP WARRANTY

    Overview

    • 435 Watt TopCon Monocrystalline Solar Panel (with Z-brackets) x 4 $636.00
    • Total $636.00
    30-day any-reason Returns

    435 Watt

    TopCon Monocrystalline Solar Panel (with Z-brackets)
    • 30-day any-reason Returns

    GENERAL SPECS

    Maximum power (Pmax) 435W
    Voltage at Pmax (Vmp) 32.13V
    Current at Pmax (Imp) 13.54A
    Open-circuit voltage (Voc) 38.75V
    Short-circuit current (Isc) 14.27A
    Temperature coefficient of Voc -0.29% / °C
    Temperature coefficient of Isc +0.043%/ °C
    Temperature coefficient of Pmax -0.330%/ °C
    Maximum System Voltage 1500V DC
    Number of Diodes 3
    Junction box IP rating IP68
    Maximum series fuse rating 25A
    Operating temperature -40°C to 85°C
    Power tolerance 0,+5W
    Standard Test Condition Irradiance 1kW/sqm, Temperature 25°C, AM=1.5
    Cell Type N type mono-crystalline TOP-CON
    Number of cells 108 (6x18)
    Cable lengh (includs connector) 1200mm
    Cable size 12 AWG
    Max test mechanical load 5400 Pa
    Panel Dimension 67.8” x 44.6” x 1.2”
    Shipping Weight 47.0 lbs (21.4 kg)
